    7 Inch Softgel Encapsulation Machine With Servo Control

    Ask Lasest Price
    Brand Name : Kunyou
    Model Number : S407
    Certification : CE,ISO9001
    Payment Terms : T/T, L/C, Western Union, MoneyGram
    Supply Ability : 30 Set/Sets Per Year
    Delivery Time : 60-90 days
    • Product Details
    • Company Profile

    7 Inch Softgel Encapsulation Machine With Servo Control


    7 Inch Softgel Encapsulation Machine , Softgel Making Machine With Micro Lubrication


    Softgel Encapsulation Machine Quick Detail


    Product Name

    Soft capsule Filling Machine

    Power consumption

    13 kw

    Control Mode

    PLC+Touch screen

    Plunger Numbers

    12

    Dimension

    880X2200X2000mm

    Dosage deviation

    < +2%



    Softgel Encapsulation Machine Product Description


    S407 Softgel Encapsulation Machine is developed based on Model S406 softgel encapsulation machine. The die roll length is 20mm longer. It combines advantages of foreign equipment and requirements of customers,considering the needs and the biggest benefits of customers as start point.There are following features besides S406’s. S407 adopts PLC operation, making operation more convenient. The die roll’s rotation rate can be regulated within 0 to 7 rpm, so users can choose the most proper rotation rate according to data of different material and techniques. Drying cycle is controlled by PLC unified, so users can regulate the cycle time conveniently. The tumbler dryer is designed with a device to remind operators to prepare well when discharging. S407 can realize the function of statistical statements and printing. The machine drive system’s lubrication pump is droved by motor alone, which greatly improves the lubrication performance when main equipment operating at a very slow speed. At the same time, it can reduce machine vibration, prolong machine overhaul time and save investment for users.

    7 Inch Softgel Encapsulation Machine With Servo Control
    7 Inch Softgel Encapsulation Machine With Servo Control
    Specifically speaking, it has the following characteristics:
    Dosage deviation:< +2%
    Material of oil roller: porous stainless steel
    Parallel degree of main shaft of the die rolls:<0.02mm
    Micro gelatin ribbon oil lubrication
    Precision temperature control for injection wedge, spreader box and chilled water.
    The running parameters can be stored and recalled with a finger tip touch if necessary.
    Pneumatic wedge lift up.
    Pneumatic left die shaft movement.
    Softgel Encapsulation Machine Application
    It’s mainly for softgel making enterprises and pharmaceutical enterprises and universities.
    Softgel Encapsulation Machine Specification

    Model

    S407

    Die roll

    Ф103X172mm

    Die roll speed

    0~7rpm

    Plunger numbers

    12

    Overall dimension

    880X2200X2000mm

    weight

    1200kg

    Power consumption

    13 kw

    Control mode

    PLC+Touch Screen

    Output rate

    8#OV 50000-70000 pcs/hour

    7 Inch Softgel Encapsulation Machine With Servo Control


    Softgel Encapsulation Machine Competitive Advantage


    1. PLC operation
    2. Improve the efficiency of production largely
    3. Adjustable rotation rate during 0-7rpm
    4. Compact and beautiful
    5. It can be assembled or disassembled with single hand
    6. Reduce the oil consumption
    7. Adjustable separately or automatically
    8. The control system has a counting function to make operators get the number of pills clearly
    9. Store and apply operating data
    10. Lengthen the life of die roll by using pneumatic
    11. Reminding and diagnosing faults function
    12. Can realize the function of statistical statements and printing
    13. More safety
    14. The cable plug has good waterproof and oil proof function
    Soft capsule/softgel making machine, paintball making machine, Tumble drying machine, gelatin melting tank
